AS-450 Quick start Guide
Main menu
•
Print Image: Select, Import or Delete an
image.
•
Printer Setup: Set Printer parameters to
adjust the Printer.
•
Tools: Run Ink Cost Estimator, Ink Status,
Diagnostic tests, Network, and Screen
Calibration.
•
Print Data: Display information about the
job printing.
•
Test Print: Print a test page using current
adjustments and print parameters.
•
Info: Display information about the Printer.
Install inkjet cartridges
To install inkjet cartridges,
open latch lever fully, place
cartridge into pen stall and
push until it bottoms out in
pen stall. Close latch lever.
For additional information on your adressing system please consult the
user guide:
kb.quadient.com/as450_ug_en
1 - Set Up the Media Transport System
Sheet Separation & Guide Adjustments
a
b
2. Loosen Separator Locking
3. Place one piece of Media in
Knobs
(a)
and raise all Se-
parators. Tighten Locking
Knobs to hold Separators
in raised position.
5. Tighten Separator Locking
4. Loosen Separator Locking
Knobs
(a)
for Separators
that have Media under-
neath them.
6. Tighten Media Side Guide
7. Place a stack of Media into
(c)
Locking Knobs
to secure
Media Side Guide positions.
c
2 - Position Print Units
1. Loosen locking knob (a).
2. Position Print Unit as needed to
1. Loosen the Media Side
Guide Locking Knobs
and move Media Side
3. Secure locking knob
(b)
Guides
to their ou-
termost positions.
3 - Media Thickness Adjustment
center of Feed Table and po-
sition it under the Separators.
To adjust media thickness:
1. Turn Media Thickness Knob
2. Slide a piece of media
Printheads
3. Adjust the Media Thickness Knob
Knobs
(a)
and adjust Media
counter-clockwise until the bottom
Side Guides (b) so they are
of the Print Unit just touches the
about 0.8 mm from sides of
media. Then remove the media.
Media.
4. Position the Exit Pressure Roller
Assembly so it rides on the media.
5. Turn Printer ON.
the hopper then tighten
Locking Knob (d).
d
achieve the desired print location
on media being fed.
(a).
(a)
fully
(b)
under
(a)
a
a
b
A0136344/A - 29/10/2020
1/4
