• A ssemble the bottom plate (20) again and fix
the 4 screws.
Make sure that the top of the base plate
is securely closed before operating the
machine.
Mounting the dust bag
Fig. A
For dust extraction the dust bag (13) can be used.
Connect the dust extraction adapter (12) to the
machine, then connect the dust bag (13) to the
adapter. Empty the dust bag regularly so that the
vacuuming performance remains intact.
A vacuum cleaner can be directly connected to
the dust extraction adapter when use of a vacuum
cleaner is preferred.
5. OPERATION
Never use the spindle lock while the
machine is running.
Switching on and off
Fig. A
• T o switch the machine on slide the on/off
switch (1) forwards.
• T o switch the machine off, depress the on/off
switch (1), the switch will automatically move
to the 'off' position.
Never use the spindle lock to stop the
motor.
Marking the workpiece
Fig. E
Before starting with the Biscuit Jointer the
workpieces must be marked as following.
• P lace the two surfaces which must be
connected, with their connecting side to each
other
• C lamp the work pieces and mark the center of
the groove by drawing a perpendicular line
• S everal joints will be required for larger
workpieces. The distance between two drawn
lines should be at least 10cm.
8
Downloaded from www.Manualslib.com manuals search engine
Sawing grooves
Fig. F
• S et and check the cutting depth on the
machine
• S et the angle on the machine
• S et the height on the machine, take care for
setting the height, the groove for the biscuit
dowel must be in the middle of the workpiece.
• M ake sure the workpiece is securely clamped
• P osition the machine on the workpiece, the
marked centerline (15) must be in line with the
line drawn on the workpiece
• H old the machine with both hands and switch
the machine on.
• P ush the motor base carefully forward as far
as possible.
• M ove the motor base backward and switch the
machine off.
For workpieces thinner than 16 mm it is
not possible to cut the groove in the
middle of the workpiece without adding
an adjustment plate below your
workpiece (fig. G).
Joining the workpieces
When the grooves in both workpieces have been
made the workpieces can be joined together.
• P ut glue in both grooves.
• P lace the biscuit dowel in the groove of one
workpiece.
• P lace the other workpiece on the biscuit
dowel.
• F asten the workpieces and wait till the glue is
dry.
User tip for connecting two workpieces
• S aw a groove as big as one biscuit into the first
workpiece
• P lace the biscuit with good glue (according the
material) into the groove
• S aw a longer groove into the other workpiece
• N ow both workpieces can be positioned easily
towards each other (clearance to correct)
• F asten the workpieces and wait till the glue is
dry
Move the machine in the same direction
as the direction of rotation. See arrow on
top of the machine.
