Rear carrier
YAMAHA FZ 1 Fazer
from date of manufacture 2006
Item - No.:
4004-026-201 black
Assembling instructions
The kit contains the following parts:
Quant item no.
description
1
799.997
alu-rack
1
799.904
plastic cover for rack
1
704.261HB
pipe strut left
1
704.262HB
pipe strut right
1
704.263HB
crossing brace
4
150.763
allen screw
M6 x20
4
150.809
washer ø6,4
4
150.164
special washer
20 x 20 x ø6,4
4
150.799
self lock nut M6
6
150.923
fillister headscrew
M 8 x 30
2
150.938
fillister headscrew
M 8 x 20
2
150.892
fillister headscrew
M 8 x 45
4
151.022
special self-lock nut M8
8
150.810
washer ø8,4
1
330.300
emblem „KRAUSER"
Notice:
it is not possible to mount this rear rack together with the 4004.026-111(Lock it System) side carrier.
