Brink 6602 Montageanleitung Seite 3

B
6602/7
M12x40(10.9)
M10(10)
A
120Nm
45Nm
I
J H
G
L
6602/6
M12x45(10.9)
120Nm
6602/4
M12x45(10.9)
75Nm
6602/2
K
P
M12x40(10.9)
120Nm
6602/5
B 6602/7
M
O
D
A
9520092
C
M10(10)
N
660280
45Nm
9530920
E
6602/3
M12x90(10.9)
120Nm
F
M12x45(10.9)
75Nm
