Hardware Installation - D-Link DU-562M Schnellinstallationsanleitung

Please unplug the telephone Line and plug the telephone line into the socket on
the back of the modem marked LINE.
A. Insert one end of an USB cable to the USB port on the back panel of the
DU-562M. The Power LED will turn ON to indicate proper operation.
B. Use the Phone cable included with the Modem to connect it to the telephone
wall socket. Plug one end of the cable into the PHOME port on the rear
panel of the Modem and insert the other end into the wall socket.
Downloaded from www.Manualslib.com

Hardware Installation

A. This is the
connection for
USB Cable
you Computer
USB Port.
manuals search engine
B. This is the
connection for
Phone Cable
to
ISP Provider.
2
