Part nr. 902932-01
Adjust the depth setting of the whiteboard stop.
13
Loosen the 3 screws on top of the whiteboard stop and adjust forward or backward.
Tighten the screws again after adjusting the depth setting.
Keep a minimum space of 2,5 cm / 1" between the whiteboard and the screen.
Adjust the Whiteboards.
14
Loosen the screws on the top and bottom hinge and adjust the depth.
When the Whiteboard is parallel to the screen, tighten the screws on the top and bottom hinge.
14.1
Whiteboard not parallel to screen
Not O.K.:
Whiteboard frame for the BalanceBox
2,5 cm
1"
14.2
Whiteboard parallel to screen
21
Winx-4b 75"
®
O.K.:
650
