Thomas Regout BalanceBox Winx-4b Installationsanleitung Seite 13

75”

Werbung

Part nr. 902932-01
6
Hang the screen onto the BalanceBox
6.1
7
Lock the VESA bracket with the lock screws.
Use 2x M6x12 from "Bag of screws D" (Art. no.: 539962)
®
650
Make sure the screen sits correctly in both horizontal brackets
Whiteboard frame for the BalanceBox
D
2x
13
Winx-4b 75"
1:1
2x M6x12
®
650
