MAFIXTILMOBG0000 MABOLI0490 (E.G. INGENUA, MULTI SPECTRA, ...) ICARUS Dimensions are indicative. Final responsibility always lies with the installer. Maten zijn informatief. Eindverantwoordelijkheid ligt bij installateur. Les dimensions indiquées sont seulement à titre informatif. La responsabilité nale incombe à l’installateur. Die Maße sind nur informativ. Der Installateur trägt die Verantwortung für die Ausführung.
INSTALLATION DIMENSIONS 17 cm / 9,69” 12,2 cm / 4,8” Ø10 mm / 0.4” 300 / 9’10 Ø21,5 cm 8,46” Ø26 cm 235 / 7’ 9” 420 / 13’ 9” 10,24” UMBROSA /...
Seite 6
TILE BASE INSTALLATION OPTIONS UMFIXTILMOBG0000 UMFIXTOPMOBA0000 UMFIXTILES120000 UMBASM80FL017EXT MAFIXTILMOBG0000 MABOLI0490 MACOMU020B UMBASEWHEELH00 UMBROSA /...
Seite 7
TILE BASE INSTALLATION OR OPTION : UMBASM80FL017EXT 1’ UMBROSA.COM UMBROSA /...
Seite 8
TILE BASE INSTALLATION OR OPTION : UMBASEWHEELH00 UMFIXTILES120000 1’’ TILES 40x40 CM NOT INCLUDED UMBROSA /...
Seite 9
TILE BASE INSTALLATION OPTIONAL : UMFIXTOPMOBA0000 FRAGILE SURFACE COVER DURING ASSEMBLY UMBROSA /...
Seite 10
Les dimensions indiquées sont seulement à titre informatif. La responsabilité nale incombe à l’installateur. Die Maße sind nur informativ. Der Installateur trägt die Verantwortung für die Ausführung. Los tamaños son sólamente informativos. El instalador es responsable del acabado nal. Dimensioni sono indicative. La responsabilità nale spetta sempre all’installatore. UMBROSA /...
Seite 11
CONCRETE ANCHOR INSTALLATION SHADE SHADE UMBROSA /...
Seite 12
CONCRETE ANCHOR INSTALLATION GRASS GRAVEL TILES 10 cm 4 cm UMBROSA /...
Seite 13
CONCRETE ANCHOR INSTALLATION UMBROSA /...
