Installing The Hardware - D-Link DAP-2690 Installations Anleitung

* 2.4GHz antenna connectors are located on the bottom of the access point.
* PoE kit (injector and adapter) is NOT include in the package and it can be purchased
with the model name "DPE-101GI".
D-Link DAP-2690 Quick Install Guide
Downloaded from www.Manualslib.com

Installing the Hardware

5GHz Antenna Connectors*
Reset Button
Console Port
manuals search engine
LAN Port (PoE)
Power Receptor
(*Note no longer
used, replaced
by PoE)
