FILL-RITE 800C Serie Gebrauchsanweisung Und Sicherheitsvorschriften Seite 3

ITM. PART
NO. NO. DESCRIPTION
1 800G2246 Counter Cover
2 800G0208 Counter Face, U.S. Gallon
800G0241 Counter Face, Liter
3 800G8870 Knob
4 800F4080 Counter - U.S. Gallon
800F4081 Counter - Liter
5 800G2246 Meter Cover
800G2247 Meter Cover, Nickel Plated
800G2248 Meter Cover, Teflon® Coated
6 800F4191 O-ring (5-106) Fluorocarbon
800F4033 O-ring (5-106) EPDM
7 800F3980 Washer
8 800F3845 Drive Gear (70T) - U.S. Gallon
800F3846 Drive Gear (84T) - Liter
800F4185 Drive Gear (73T) - Imperial Gallon
9 800F3820 Shaft, Cluster Gear
10 800F3841 Cluster Gear (22T/67T) - U.S. Gallon
800F3843 Cluster Gear (10T/67T) - Liter
800F3541 Cluster Gear (19T/67T) - Imperial Gallon
11 800F3830 Washer
12 800G2250 Gear Frame Assembly
13 900F4007 #8-32 x 5/16 PHMS ACR II
18 700F2800 O-ring (-218), Buna-N ( 800A, 700A/B)
700F2801 O-ring (-218), Fluorocarbon (800A, 700A/B)
800G2601 O-ring (-218), EPDM (800A, 700A/B)
19 800G2236 3/4 Inlet - 3/4 Outlet Housing
800G2237 3/4 Inlet - 3/4 Outlet Hsg., Nickel Plated
800G2238 3/4 Inlet - 3/4 Outlet Hsg., Teflon® Coated
800G2242 1 Inlet - 1 Outlet U.S. Housing
800G2243 1 Inlet - 1 Outlet U.S. Hsg., Nickel Plated
800G2244 1 Inlet - 1 Outlet U.S. Hsg., Teflon® Coated
800G2255 1 Inlet - 1 Outlet BSPT Housing
800G2256 1 Inlet - 1 Outlet BSPT Hsg., Nickel Plated
800G2257 1 Inlet - 1 Outlet BSPT Hsg., Teflon® Coated Opt.
Find Quality Products Online at:
6"
150 mm
8"
200 mm
GlobalTestSupply
www.
800C METER PARTS LIST
ITM. PART
QTY.
NO. NO.
1 20 800G8892 5/16-18 x 1 HWTRS
1 21 800F4463
22 800F4449
Opt.
1 800F3389
1 23 800F4440
Opt. 24 800F4036
1 800F4034
Opt. 25 800F4010
Opt. 800F4011
1 800F4032
Opt. 26 800G2262 Meter Chamber Assembly - Buna-N
2 800G2599 Meter Chamber Assembly - Fluorocarbon
1 800G2600 Meter Chamber Assembly - EPDM
Opt. 27 800G2531 Meter Chamber Assembly, Buna-N
Opt.
1 28 800F3959
1 29 35F1397
Opt.
30 800G2532 Cover Assembly - U.S. Gallon
Opt. 800G2533 Cover Assy. - U.S. Gallon - Nickel Plated
1 800G2534 Cover Assy. - U.S. Gallon - Teflon® Coated
1 800G2535 Cover Assembly - Liter
2 800G2536 Cover Assembly - Liter, Nickel Plated
Opt. 800G2537 Cover Assembly - Liter, Teflon® Coated
Opt. 800G2544 Cover Assembly - Imperial Gallon
Opt. 800G2765 Cover Assy. - U.S. with EPDM Seal
1 800G2778 Cover Assy. - U.S. Nickel with EPDM Seal
Opt. 800G2900 Cover Assembly - Liter with EPDM Seal
Opt.
*These parts are in the 800C Series Repair Parts Kit.
Opt.
Opt.
Opt.
Opt.
Opt.
6"
WHEN ORDERING REPAIR PARTS, BE SURE TO GIVE
150 mm
REPLACEMENT PART NUMBER, DATE OF MANUFACTURE
AND METER SERIES NUMBER. THIS WILL ENSURE THAT
THE CORRECT REPLACEMENT PART IS SUPPLIED.
TOLL FREE CUSTOMER SERVICE NUMBER
3
DESCRIPTION
Calibration Screw (Includes Item 24)
O-ring (-012) Fluorocarbon
O-ring (-012) EPDM
Seal Screw
O-ring (-008) (Included w/Item 21) Fluorocarb 1
O-ring (-008), EPDM
O-ring (-156), Buna-N
O-ring (-156), Fluorocarbon
O-ring (-156), EPDM
(Includes Items 12 & 26)
Pinion Bevel
#4 x 3/8 PHSMS
800 634 2695
800F9146 rev 8
.com
sales@GlobalTestSupply.com
QTY.
4
1
1
Opt.
1
Opt.
1
Opt.
Opt.
1
Opt.
Opt.
1
1
2
1
Opt.
Opt.
Opt.
Opt.
Opt.
Opt.
Opt.
Opt.
Opt.
.
