Technical Data; Power Supply - X4-TECH Bobby Joey Casey Music Bedienungsanleitung

Technical data

Power supply 1.200 mAh Li-Ion accu, 3,7 V
Charging port 5 V DC Micro-USB
Output 5 W
Microphone jacks 3,5 mm AUX-in
Bluetooth 4.2
USB 1.1, 2.0/SD-cards MP3-files; the media hast o be formatted in FAT32;
capacities of up to 32 GB are supported
Dimensions | Weight 19,2 x 7,8 x 22,9 cm | around 836 g (including acces-
sories)
Delivery content Casey Music, 2x microphones, carrying belt,
Micro-USB-cable, manual

Power supply

The device has a built-in rechargable battery, which can be charged with
the provided Micro-USB-cable.
» Connect the Micro-USB-cable to an appropriate 5 V C USB-socket, like on
a computer.
» The indicator LED (Figure 1) on the frontside will start glowing red until
the device is fully recharged. The battery LED turns off after the rechar-
ging process is finished.
» One complete charging takes approx. 3 hours. The runtime is approx. 4
hours, depending on the volume.
CAUTION! The battery may only be charged under the direct supervisi-
on of adults.
WARNING! Batteries must not be exposed to excessive temperatures,
such as arise in direct sunlight, in a fire or an oven. There is an explosion
risk.
WARNING! Make sure that the batteries are not shortcircuited.
Furthermore, they must not be charged. There is an explosion risk.If there
is any doubt in the safety of this device (e.g. because of damage to the
enclosure or cables), the device should not be used until the damage has
been properly removed.
20
