The assignment of the connection leads is as follows:
Line
Brown Outer conductor
Blue Neutral conductor
Yellow/Green
The protective conductor must be connected!

3.2 Operating modes and setting of the on-board menu:

MENU - To select the operating mode.
ENTER - Activates the setting process of a menu point or saves a setting.
UP - Increases the setting value.
DOWN - Decreases the setting value.
The "VENTUS XXL" has several operating modes, all of which can be set via the on-board menu (see fig.1
housing rear). Always press "Menu" repeatedly until the function to be set is reached. With "Enter" you get to the
individual, adjustable values. Then use "Up" and "Down" to set the desired values. These can be confirmed with
"Enter". Familiarize yourself with these settings in order to be able to operate the unit optimally. You can set the
following modes and functions:
Mode Programm
Pin International
Protector
Description
Automaticprogram 1
Automaticprogram 2
Automaticprogram 3
Automaticprogram 4
Automaticprogram 5
Automaticprogram 6
Automaticprogram 7
Soundprogram 1
Soundprogram 2
Soundprogram 3
Soundprogram 4
Soundprogram 5
Soundprogram 6
Soundprogram 7
Speed of Automatikprograms
Microphoneintensity
The silent mode refers to the music-controlled
operation. If the silent mode is deactivated "OFF",
the current program of the device will continue
slowly if no further music signals (bass impulses)
are received.
L
N
20
