GEZE Slimdrive SD Zusatz-Montageanleitung Seite 9

Integrierte Schließfolgeregelung Bandseite Slimdrive SD Mat. Nr. 83221, Datei 83221 SD_IS-BS_141199.p65
Arrangement of the driving units
DIN left DIN right
1st closing leaf DIN left
Rope at the bottom
2nd closing leaf
1st closing leaf
Right: Drive of 2nd closing leaf Slimdrive SD or manual door closer (TS 5000)
1st closing leaf DIN right
Rope at the top
2nd closing leaf
1st closing leaf
Left: Drive of 2nd closing leaf Slimdrive SD or manual door closer (TS 5000)
9
