2.2 Function of Controls and Indicators
The function of the controls and indicators is shown in Fig. 3.
Note
All keys have backlit red LED's.
Index
Control / Indicator Setting /
Fig. 2
1
Display
2
Cooling ON/OFF
key
3
A/C ON LED
Fig. 3 Function of Controls and Indicators
Downloaded from
www.Manualslib.com
Function
Indication
oF
Ignition on, system in standby for
activation by pressing AUTO key.
Ventilation only is possible by pressing
ventilation key.
Number or
System in operation. Indication of
Code
temperatures, ventilation speed, failure
codes and status information depending
on system operational mode and
indication selections. For details refer to
"Command Description".
pressed
Manually selection of cooling
mode ON /OFF.
lit
A/C mode is on, system operates in
climatisation mode.
manuals search engine
Index
Control / Indicator Setting /
Fig. 2
Indication
4
AUTO mode LED
lit
5
Ventilation speed
lit
LO LED
6
Ventilation speed
lit
HI LED
7
Key ventilation
pressed
speed
8
DOWN key
pressed
9
UP key
pressed
Fig. 3 Function of Controls and Indicators
CC 145
Function
AUTO mode is on, system operates in
AUTO mode.
Indication of ventilation speed LO
manually selected with ventilation key.
AUTO mode LED is off.
Indication of ventilation speed HI
manually selected with ventilation key.
AUTO mode LED is off.
Manual selection of blower speed LO
or HI with up / down keys to override
automatic AUTO mode ventilation speed.
Indicated at first.
Down control for system settings and
readings in the different operational
modes including testing and system sta-
tus readouts.
Up control for system settings and read-
ings in the different operational modes in-
cluding testing and system status
readouts.
15
