Per il passaggio del cavo d'alimentazione é possibile sfondare le pareti in corrispondenza
delle frecce "A".
EN
The supply cable can be run through the walls (an opening can be made in them) where
indicated with the arrow "A".
ES
Para entroducir el cable de alimentación es posible traspasar las paredes a la altura de
las flechas "A".
B
P
8,0
IT
Per la corretta chiusura della basetta "B", posizionare il particolare come indicato in figura,
evitando la schiacciatura dei cavi elettrici.
EN
To close the base "B" correctly, position the components as shown in the diagram, without
flattering the electrical wires.
ES
Para el cierre correcto de la base "B" colocar los detalles conforme indica la figura
evitando el aplastamiento de los cables eléctricos.
4
10
mm
9 Nm
60
mm
8
~ 9
mm
