"WIŚNIOWSKI" Sp. z o.o. S.K.A. does not take any responsibility for any
consequences and damages resulting from unintended product application or
installation.
[C000157] Modifications are prohibited unless permitted by the manufacturer.
Repairing and maintenance should be performed by a licensed Professional
Installer or Competent Person.
[C000200] Zinc coating is not for decoration purpose but protects against cor-
rosion. Waste and packaging materials (plastic, cardboard, polystyrene, etc.)
comply with current European standards. Nylon and polystyrene packaging
should be kept out of children's reach.
[C000201] 8. INstallatIoN PRoCEDURE
Proper operation depends from correct installation to a great extend.
"WIŚNIOWSKI" Sp. z o.o. S.K.A. recommends authorized installation compa-
nies. Safe and intended use of the product can only be ensured by correct instal-
lation and maintenance in accordance with the instructions, and by competent
entities or persons.
[C000064] 8.1. INstallatIoN
Fence stability depends from the proper installation to a great extend. When
installation is performed by a user, the instruction guidelines should be followed
to avoid improper installation and possible loss of the warranty.
It is prohibited to use the fence structural elements to fix the fencing system ele-
ments, etc.
[D000446] Prior to construction of the fence, it must be
checked if the materials used do not contain contraindi-
cations to the use with galvanized and painted coatings.
[C000203] 8.2. PRElIMINaRY vERIfICatIoN
Prior to installation, check if the fence and its parts are operable. All fence mate-
rials and parts should be intact and fit to use.
[D000297] 8.3. assEMblY aCCEssoRIEs
Parts of various assembly kits - fig. 1.
[D000085] 8.4. sEGMENt INstallatIoN
Fence segments may be installed on a steel post (type UM) or concrete post
(type UB). For steel posts, install the assembly bracket - fig. 2.
For concrete posts, drill the holes in the post, and then install the bracket using
a wallplug - fig. 3.
[D000086] Fasteners to mount the segment bracket to the brick or steel post are
not supplied by "WIŚNIOWSKI" Sp. z o.o. S.K.A. with a product. Order them
separately, or purchase them by yourself.
• Steel post - self-tapping screw 6.3x25
• Brick post - universal frame anchor Hilti HRD-HF 10x80 or anchor of other
manufacturers with the capacity parameters similar to the above mentioned.
[D000082] 8.5. INstallatIoN UM8/Ub8 - fIG. 4 - 7
• [D000305] Place the fence segment on the anchors fastened to the posts.
• Bolt the segment to these anchors. Repeat the procedure for each anchor.
• Repeat the steps to install next segments.
[D000087] It is allowed to shorten the segment to adjust its
width to the distance between the posts. Minimum dis-
tance between the vertical hollow section and the place of
cutting is 45 [mm] - fig. 8. Drill the hole fi 8 in the horizontal rail - fig.
9. the place of cutting should be protected with anti-corrosive prim-
er and finishing coat acc. to the paint manufacturer, or with zinc-
rich paint - fig. 10.
[C000182] 8.6. PaINtING
When required, zinc layer losses should be repaired with anti-corrosive primer
and finishing coat, according to the paint manufacturer instructions, or with
a zinc-rich paint.
[A000008] 9. ENvIRoNMENtal PRotECtIoN

Packaging

Elements of packaging (cardboard, plastics, etc.) are classified as waste suit-
able for recycling. Follow local legislation for specific material before throwing
it away.
Product scrapping
The product consists of many different materials. Most of the materials used are
suitable for recycling. Sort it before disposal, and then deliver to refuse collec-
tion and disposal area for recycling.
follow local legislation for specific material before
scrapping.
Technical description IIiO/OPo/Segmenty-BASIC/05/2013/ID-93803

Installation and Operating Instructions – Residential fences – segments BASIC
[A000009] Remember! Recycling of packaging materials
saves natural resources and reduces the amount of
wastes.
[C000171] 10. DIsassEMblY
For disassembly, perform the installation procedure in the reverse order.
[C000175] 11. RoUtINE MaINtENaNCE INstRUCtIoNs
Annual inspections performed by authorized service company are recommend-
ed. Check the condition of all connections made during installation, and adjust
if necessary.
[C000207] activities which may be performed by the owner after
careful reading the instructions
Protect the fence against corrosive substances like: alkalis, acids, etc. Follow the
product maintenance guidelines. Powder-coated elements should be cleaned at
least once in a year, or more often if soiled considerably.
[B000046] Observe the following cleaning rules:
• For washing, use pure water with small amounts of a neutral or slightly alka-
line detergent, with non-scratching clothes.
• Painted surfaces must be cold to be cleaned - max. temperature 25° C.
• Only cold cleaning media may be used - max. temperature 25° C.
• No acidic or strongly alkaline cleaners/ scratching agents that can attack
the steel base.
• No scratching agents or cleaners that scratch or damage the paint.
• No organic solvents which contain esters, ketones, alcohols, aromatics, gly-
col ether or chlorinated hydrocarbons, etc.
• No cleaning agents of unknown composition.
• No cleaning materials that leave remains on a cleaned surface.
• Fat, oil or soot spots can be removed with non-aromatic petrol hydrocarbons.
• Glue, silicone rubber or adhesive tapes remains can be removed with non-
aromatic petrol hydrocarbons.
Maximum treatment time may not exceed 1 hour. Cleaning may be repeated
after at least 24 hours if required.
Glue, mortar, putty, filler, masking and adhesive tapes may contain aggres-
sive chemicals, so their effect on paint coating and the base must be tested
before usage.
Never use water jet, pressure washers, or water vacuum cleaners.
[C000206] Periodically check the following:
• the fastening of all threaded joints;
• the overall technical condition of the fence.
[C000182] Painting
When required, zinc layer losses should be repaired with anti-corrosive primer
and finishing coat, according to the paint manufacturer instructions, or with a zinc-
rich paint.
[A000046] "WIŚNIoWsKI" sp. z o.o. s.K.a. is not respon-
sible for damage effecting from disregarding safety regu-
lations, the operation instruction, and law requirements.
[C000183] All activities must be performed according to this Installation and
Operating Instruction. Any comments or recommendations must be submitted to
the Owner in writing.
[A000012] "WIŚNIoWsKI" sp. z o.o. s.K.a. reserves the right to
introduce design modifications due to technological progress that
do not alter the product functionality, without prior notice.
this documentation is copyright of "WIŚNIoWsKI" sp. z o.o.
s.K.a. Copying, reproduction and usage in full or in a part with-
out the written consent of the owner is prohibited.
[A000048] this document has been translated from Polish. In case
of discrepancies, the Polish version prevails.
