2. In the [TCP/IP] dialog box, make sure that [Ethernet] is
selected in the [Connect Via:] field. If [Using DHCP Server]
is already selected in the [Configure:] field, your computer is
already configured for DHCP. Close the [TCP/IP] dialog box,
and skip to Step 2 Disable HTTP Proxy.
3. Select [Using DHCP Server]
in the [Configure] field
and close the window.
4. Another box will appear asking whether you want to save your
TCP/IP settings. Click [Save].
33
Step 2. Disable HTTP Proxy
You will need to verify that the HTTP Proxy feature of your Web
browser is disabled so that your Web browser is able to view the
configuration pages inside your SMC7804WBRB. The following
steps are for Internet Explorer and for Netscape. Determine which
browser you use and follow the appropriate steps.
Internet Explorer
1. Open Internet Explorer and click the [Stop] button. Click [Edit]
and select [Preferences...].
