GETTING TO KNOW YOUR ROBO.COM² CLEANER
Robo.com² Top View
1
2
1 Front Bumper
2 Infra Red Receiver
3 Auto Charge Contacts
4 Soft Furniture Protector
5 Sensor Window
6 Display Screen
7 Dust Container Release Button
8 Floor Sensor
9 Front Wheel
10 Battery Cover
11 Edge Cleaning Brush
Robo.com² Bottom View
8
9
8
10
11
8
12
13
* Certain Models Only
** May vary according to model
RoboCom2Manual2011__GB.indd 3
Downloaded from www.Manualslib.com
3
14
manuals search engine
Robo.com² Top View
4
12 Right Drive Wheel
13 Power Switch
14 Charging Connector
15 Exhaust Grille
16 Dust Container
17 Floor Polisher Pad*
18 Floor Polisher Pad Holder*
19 Floor Brushes Release Latch
20 Floor Brushes
21 Left Drive Wheel
22 UV Lamp*
7
6
5
22*
8
21
20
19
18*
17*
16
15
