– Lock your vehicle from the passenger side.
– If the driver's door is locked, a servo motor is fitted.
– If the driver's door is not locked, a servo motor must be fitted in the driver's door (e.g.
WAECO Art. No. ML-11).
Locking the Central Locking Mechanism
The central locking is closed by pressing the upper button of the manual transmitter. The
indicator lights will flash once as confirmation.
Unlocking the Central Locking Mechanism
If you press the upper button of the manual transmitter again, the central locking is
released. The indicator lights will flash twice as confirmation.
No.
(see B 1)
(see B 2)
(see B 3)
Needed/required for installation:
– Measure
– Prick punch
– Hammer
The following tools are required for the electrical connection and testing:
– Diode test lamp
or voltmeter
– Crimping pliers
– Insulation tape
For securing the receiver and cables, you may also need bolts, metal screws and cable
binders.
Downloaded from www.Manualslib.com
30/07/03 11:41 Page 36
Preconditions for functioning of the remote control

Remote Control Functions

Quantity
1
1
1
(see C 1)
(see C 2)
(see C 3)
(see D 1)
(see D 2)
(see D 3)
manuals search engine

Scope of delivery

Description
RF receiver
RF hand transmitter
Connection cable for receiver

Tools required

– Drill bits
– Drill
– Screwdrivers
– Heat shrinkable tubing
– Hot blow drier
– Soldering iron
– Solder
36
Article No.
RC-100RX
RC-100TX
RC-100KA
(see C 4)
(see C 5)
(see C 6)
(see D 4)
(see D 5)
(see D 6)
