Resol V40 Handbuch Seite 15

Technical data
Type
Version
Impulse rate
Nominal width
Connection thread at the counter
Connection thread of the fitting
Max. operat. pressure
Max. operat. temperature
Nominal flow
Maximum flow
Insulation limit ± 3 %
Minimum flow horizontal
Minimum flow vertical
Art. no.
Pressure loss curve see page 42-43!
V40-35
2
l/Imp 25
DN 25
G...B " 1 ¼
R... " 1
P bar 16
max
T °C 130
max
Q m /h 3.5
3
n
Q m /h 7
3
max
Q l/h 280
t
Q l/h 70
min
Q l/h -
min
280 013 60
V40-60 V40-100
2 2
25 25
25 40
1 ¼ 2
1 1 ½
16 16
130 130
6 10
12 20
480 800
120 200
- -
280 013 70 280 013 80
V40-150
2
25
50
2 /
3
8
2
16
130
15
30
1200
300
-
280 013 90
15
