Irradiation impeller DN25/DN40/DN50
A mounting length without fitting
B total height
C height at centre of pipe
H height with flange
weight with fitting
weight without fitting
Horizontal mounting is possible
14
3.5 m³/h 6.0 m³/h 10 m³/h 15 m³/h
260 mm
143 mm 169 mm
100 mm 123 mm
152 mm 192 mm
3.2 kg 3.2 kg 6.4 kg
2.7 kg 5.3 kg
300 mm
183 mm
126 mm
204 mm
7.4 kg
5.8 kg
