Krauser 4002.021.201 Montage Seite 4

Rear carrier
KAWASAKI ER-6n/f
Item - No.:
4002.021.201 black
Assembling instructions
quant item no. description
1 702.119 rear carrier
1 702.236 pipe strut left
1 702.237 pipe strut right
1 702.238 mounting adapter left
1 702.239 mounting adapter right
4 150.905 fillister head screw M 6 x 20
4 150.937 fillister head screw M 8 x 16
4 150.938 fillister head screw M 8 x 20
4 150.799 self-lock nut M 6
8 150.809 washer ø6,4
4 150.810 washer ø8,4
4 150.986 body washer ø6,4 x ø18 mm
4 150.733 flange screw M 6 x 20
1 150.533 carrier part K-Wing
1 330.300 emblem „KRAUSER"
2 270.102 plastic plug ø16 mm
Control all screw connections after the assembly for tightness!
Please notice our enclosed service information.
