Desmontagem dos componentes originais
Desmontagem do assento do passageiro
Insira a chave na fechadura (A) e rode-a até ouvir o estalido de de-
sengate do assento do passageiro (B). Remova o assento do passa-
geiro (B), retirando-o para a parte dianteira da moto.
3
B
Removing the original components
Removing the passenger seat
Insert the key into the seat lock (A) and turn it until the passenger
seat catch (B) disengages with an audible click. Remove passenger
seat (B) sliding it towards the motorcycle front side.
