AC power connection

HT-SB350(W)
HT-SB350(BK)
ENGLISH After checking all the connections have been made correctly,
connect the AC power lead to the AC power input socket, then
to the wall socket.
Using with the AC/DC adaptor
1
Plug the AC power lead into the AC/DC adaptor.
2
Plug the AC/DC adaptor cable into the DC IN socket
on the unit.
3
Plug the AC power lead into a wall socket. The
STAND-BY indicator will turn RED when AC power is
applied.
E-13
HT-SB350_A6_EN_UK.fm
Downloaded from www.Manualslib.com
2010 August 16
manuals search engine
AC/DC Adaptor Cable
DC IN socket
(DC 12 V)
AC power lead
1
Wall socket
(AC 100 - 240 V ~ 50/60 Hz)
Notes:
Unplug the AC/DC adaptor from the wall socket if the unit will
not be used for a long period of time.
Use only the supplied AC/DC adaptor. Using other AC/DC
adaptor may cause an electric shock or fire.
2
RIGHT LEFT
LINE IN 2 LINE IN 1
AC/DC Adaptor
