A 1 – Application
5.

Application example

A 1 with CD player and DVD player
Stereo out
CD player
• Connect a CD player to the input 2
listen to alternatively with your hi-fi system (e.g. home cinema).
• To listen to the sound via headphones you can use the buttons
or input 2 = DVD player). This means the A 1 provides either the audio signal of the CD player or DVD player.
• The signal of the DVD player is also permanently present at the output socket-
the looped through audio signal via your hi-fi system, even when the A 1 is turned off.
• An intelligent, microprocessor-controlled relay allows noiseless switching between the two different sound sources
and avoids unpleasant noise when turning the A 1 on or off.
Downloaded from www.Manualslib.com
Output
amplifier
Input 1
A1
of the A 1 and a DVD player to the input 1
manuals search engine
Stereo in
Input 2
to select the sound source (input 1 = CD player
Loudspeaker
Stereo out
DVD player
to which you would like to
. This means you can listen to
19
