Sophos UTM 110 Montageanleitung

Mounting Instructions
UTM 110/120 Rack Mounting Kit
Scope of supply
The rack mounting kit can only be used with UTM 110/120 rev. 5.
In addition to the rack mounting kit contents, you will need a long-handled
Phillips-head screwdriver.
Attach the rack mounting kit device holders
to the chassis
Secure the device holders to the appliance using four screws on both sides.
The device holders must only be fixed to the appliance by means of the
supplied screws. Screws with other dimensions might damage the appliance.
Install the power adapter
Place the adapter on the bracket. Pay attention to the direction of the power
outlet of the adapter. Secure the position of the adapter with the supplied
bevel.
Attach the power adapter bracket either to the left or right side of the rack
mounting kit.
2 device holders (left, right)
1 bevel, 1 adapter bracket, 14 screws
