1. Properly install 3 AA batteries (included to the set) observing the correct polarity + -.
2. The device will beep one time.
3. The device will start calibration (heating up of the sensor). Diodes (red, green and yellow) will all
flash one by one and you will see "888" on the backlit display.
4. After approximately 1-2 minutes the backlight will be off and the display will show "0 ppm".
5. The detector will turn into standby mode.
6. The green diode will flash every 4 secs. indicating that the device is operational, and the display will show
ppm value.
7. Do not press the TEST button when the sensor is heating up.
8. When the sensor is fully operational, test the device with TEST button.
TEST OF THE DEVICE – at least once per week.
1.Regular testing of the detector is required to check if its power supply is in running order and proper operation of the
device.
2. Press the TEST button.
3. The backlight of the display will be turned on and information will be presented on the screen.
4. You will hear four beeps and the red ALARM diode will flash four times at the same time. The device will display the
highest CO concentration which has been detected since it was tested for the last time with a TEST button.
5. The device will shortly beep one time and it will start self-testing. The screen will display information, as presented in
table 1, and all diodes, red, green and yellow, will flash one by one.
6. When the self-test is successfully completed, the screen will display "PAS" with three beeps and all three diodes will
flash simultaneously three times. The screen will display "CO" with no backlight and then "0ppm".
7. If the self-test was faulty, the screen will display "Err", the yellow diode will flash two times and the buzzer will beep two
times at the same time. The above will be repeated every 60 seconds.
8. When testing the device make sure its sound is well heard in all bedrooms.
9. Never use open fire to test the device.
10. Never place the device close to your ears when detecting or testing as it may cause serious damage to your hearing.
HUSH FUNCTION:
It is possible to hush the alarm sound of the device. In order to do that, press TEST button when the CO detector is
alarming and it will be hushed for 5 minutes. If the CO is still at the dangerous level, the detector will continue to alarm.
Table 1.
LCD display
Information on LCD
display
CO concentration
between 30-999 ppm.
Blue backlight is on. Red
"for example"
diode flashes.
„ttt" displayed on the
screen. Red, green and
yellow diodes flash one by
one.
Brief information: "888"
ppm is displayed for
approx. 1-2 minutes, after
installation of batteries.
Blue backlight is on.
OPERATION OF THE DEVICE
Alarm sound
4 short beeps,
repeated every 5
seconds.
One short beep at the
beginning of self-test.
None.
(standard operation
provides for three
short beeps after
battery installation)
12
Status of the
Recommendation
device
Alarm
Refer to What to do when
the alarm sounds.
condition.
Concentration
of CO
detected.
If the status of the
detector is normal, the
LCD will display "PAS". If
Self-testing.
the status is non-
standard, "Err" will be
displayed with two short
beeps every 60 seconds.
Self-testing
CO has not been
when first
detected. Numbers shown
powered up.
for test purposes only.
