When selecting installation place, make sure that the alarm signal will be well heard in other rooms. It is
recommended to install CO detector on every floor of the multilevel building.
It is perfect if CO detector is installed in line with the below indications:
1. In every room with a device that combusts fuels.
2. In rooms distant to the above specified rooms, where residents spend most of their time.
3. In every bedroom.
4. At least 150cm from any fuel combusting device.
5. At eye level (ca. 150cm-200cm from the floor). Above the door/window level, but still at least 150mm from the
ceiling.
6. In rooms longer than 10m it is recommended to install 2 or more detectors, at max.10m distance from the
respective detectors.
If you have a limited number of carbon monoxide detectors, use the below recommendations when selecting
their installation place:
1. Install the detector in a bedroom, if the fuel burning device is in the sleeping area.
2. Install in every room, where there is a fuel burning device with a closed or open combustion chamber.
3. Install in rooms where residents spend most of their time (e.g. in a living room).
4. Install in a single-room apartment, as far as possible from the stove/heater, but close to the sleeping area.
5. If the fuel burning device is located in a rarely used room (e.g. boiler-room), install the detector just right
outside this room, to make the alarm signal audible.
NOTE! – please keep in mind that the alarm signal has highly elevated noise level!
Where not to install your CO detector!
1. Do not install within 60cm from any heating or cooking appliances.
2. Do not install outside the building.
3. Do not install in closed spaces (e.g. inside the cabinet, or under the cabinet).
4. Do not install near vents, flues, chimneys or any other forced/unforced air ventilation openings.
5. Do not install near ceiling fans, doors, windows or other areas directly exposed to the weather.
6. Do not install in dead-air spaces, such as peaks of vaulted ceilings or gabled roofs, where CO may not reach
the sensor in time to provide early warning.
7. Do not install above the heat sources, e.g. heaters.
8. Do not install in covered areas, e.g. with curtains or furniture.
9. Do not install in areas where the detector could be damaged, knocked down or where it could be accidentally
switched off or removed.
10. Do not install near paints, dissolvents, diluting agents or air-fresheners.
11. Do not cover the ventilation slots of the device.
NOTE:
The detector detects a threat only when it is installed.
The alarm is triggered when carbon monoxide reaches the detector in described concentration and time.
This CO alarm meets these alarm response times
(as specified in EN 50291 -1:2018)
At 50 ppm, the unit must alarm within 60-90 minutes
At 100 ppm the unit must alarm within 10-40 minutes
At 300 ppm, the unit must alarm within 3 minutes
1. Use the drilling template and mark the two mounting
holes
2. Choose the suitable location and drill two openings
with 6mm drill bit.
3. Install the batteries inside the sensor and mount it on
the wall.
4. Test the device.
