STEP 4 Reattach the freezer door
10
9
Untitled-5 53
1. Use a flat-head screwdriver to remove
To prevent physical damage, use caution
when removing the screw cap.
2. Lay down the refrigerator with care.
10
9
3. Use a 11 mm wrench to remove the
4. Insert the bottom hinge (10) in the
5. Insert the freezer door and fit into
the screw cap. Then, insert the screw
cap in the opposite side.
CAUTION
Then, remove the screws from the
levelling leg (9) and the bottom hinge
(10).
hinge shaft from the bottom hinge.
Then, insert the auto closer guard as
shown.
opposite side. Then, insert the levelling
leg (9).
the bottom hinge. Then, stand the
refrigerator with care.
English 53
