Independence Looping Blue Betriebsanleitung Seite 12

3. Fold the canopy in big, horizontal S-folds (stack pack) in
the deployment bag. Bundle the lines in 3x3 "8-folds". Do
not bundle the last 50 cm of lines.
Attention: new rubber bands must be used for line
bundles with every re-pack!
2.2. Mouting the deployment bag into the harness:
1. Connect the rescue bridle with the harness bridle by
looping the bridles or with a quick link (strength > 2400
daN) and fix the connection to prevent slipping (for
example by a neopren sleeve).
Depending on the volume of the rescue system the
harness container size can be increased or decreased by
flipping a partition inside the container (fixed by velcro).
3. Close zipper of Y-bridle channel completely by sliding
the slider from the bottom to the top of the shoulder
straps. Make sure that the zipper is fully closed from the
beginning of the zipper (yellow circle) to avoid
unintended opening.
12
2
3
1
4. Close the deployment bag.
First the lower flap (1) with the upper flap (2). Then
close the left (3), then right flap (4) and secure it with
the lines.
Depending of the rescue system volume the inner or
outer grommets can be used to adjust the deployment
bag size.
2. Guide the Y-bridle in the channel to the rescue system
container and put the zipper slider down (yellow arrow).
Stow the bridle in the harness container and place the
deployment bag in the harness container. Lines of
deployment bag are facing to the bottom side.
Place a packing cord in loops of flap 1 and 4.
4. Close the container flaps by the help of the packing
cords. Close No. 1 with 2; No. 4 with 5 and 6) Place
handle-deployment bag connection in between.
4
2
4
3
1
1
4
