MANUAL - SPLBOX100/SPLBOX120
•
DISCONNECT DEVICE: Where the MAINS plug or an appliance coupler is used as the disconnect device, the
disconnect device shall remain readily operable.
DESCRIPTION OF THE CONTROLS & CONNECTORS
1. USB Input
2. SD Input
3. Bass/Treble/MIC Volume/
Echo adjust (Press MENU
button prior to rotating this
knob)
4. Light Lens
5. Previous: In USB/SD/Blue-
tooth mode: press shortly =
Previous song; Press above
3 Seconds = fast backward.
In FM mode: Short press to
go to the previous frequen-
cy, long press to go directly
to previous channel.
In LINE mode: no function
6. Menu Button to adjust Bass/Treble/MIC Vol/Echo controls. Press "Menu" for more than 3 seconds to restore
the factory settings
7. Handles
8. Tweeter (only model SPLBOX120)
9. Pause/Play: In USB/SD/Bluetooth mode this button has the Play/Pause function
In FM mode: press 3-4 seconds to scan automatically the FM radio channels. Press again to stop au-
to-searching
In LINE mode, this button has no function
10. Volume button
11. Light Lens
12. Next : In USB/SD/Bluetooth mode: press shortly = Next song; Press above 3 Seconds = fast forward.
In FM mode: Short press to go to the next frequency, long press to go directly to next channel.
In LINE mode: no function
13. Mode: Short press to cycle through FM/Bluetooth/LINE IN/USB/SD Mode
14. Record: Insert a USB/SD support and plug in the microphone prior to start recording. You can record from
the external microphone, Line in and FM input and save your record to the USB/SD storage device.
Press and hold the REC button for more than 3 seconds to start recording, Press shortly to play your
recording
15. LED Display Screen
16. Full Frequency Speaker
DESCRIPTION OF REAR PANEL
tronic
be
17. ON/OFF switch
18. Mains lead
19. LINE input (left & right) for DVD, MP3; MP4, MP5 player, PC and other audio devices
20. MIC1 & MIC2 inputs
21. FM antenna: Change the position until you get a better FM signal reception.
19
17 18
www.ibiza-light.com
20
21
EN
