EN
8. Reassemble the beam on the outer edges of the front electrostatic filter by inserting it
into the recessed channels of the Collector Electrostatic filter. After directing the beam into
the recessed channels, slide the front electrostatic filter until it clicks into its place.
9. Place the collector cell back in the unit by sliding it firmly and turning each knob to the
lock position. The collector cell is specially designed to be installed in one direction only.
10. Place the front cover back carefully.
PLACING VOC/FORMALDEHYDE FILTER
1. Pull off the electricity plug
2. Remove the front cover by pulling it gently from the top corners.
3. Remove the filter out of the cabin directly.
4. Replace it with a new filter
5. Close the front cover safely.
NOTE!
Recommended replacement interval for VOC/FORMALDEHYDE Filters is 6 months
48
