CSS AssistX AS one Gebrauchsanweisung Seite 21

LED: show settings
1
The LED shows when the sensor triggers or records. It has also the function
1
of a reassurance lamp. In addition the respectively settings are shown with the
associated colors. To see the current setting of sensitivity, range or hold time,
press the corresponding button. When pressing a button, the
represents the actual setting of the respective parameter. After release, the
LED keeps it color for 1 sec. Then it turns off.
Hold time (in Tone Mode)
5
Device in tone mode: Time span
over which the sound must be
kept in the set range.
Sensitivity
6
If the sensitivity is very high, the
sensor reacts to very quiet sound.
Tone range
7
Tolerated deviation from a taught
tone up and down.
AS one reacts on Mode:
Impulse Mode
Tone Mode
(in Tone Mode)
to all noise impulses fitting to the volume
specific to the teached in tone frequencies
Instructions for Use
AssistX AS one
1
blue: 0,5 Sek
green: 1,0 Sek
red: 1,5 Sek
yellow: 2,0 Sek
white: 2,5 Sek
blue: high
green
red
yellow
white: low
blue: high
green
red
yellow
white: low
| 21
EN
LED color
1
