Dimensional Sketch - Danfoss EvoFlat Reno Montage- Und Betriebsanleitung

Montage- und Betriebsanleitung / Mounting and Operating guide
8. MASSSCHIZZE /
1 2
A
B
C
D
E
F
1 2
65 65
G
H
1 2
Anschlüsse / Connections:
1. Heizungs-Vorlauf (HVL) /
2. Trinkwarmwasser (PWH) /
3. Primärseite (FW-Vorlauf) /
4. Primärseite (FW-Rücklauf) /
5. Kaltwasser (PWC) / Domestic cold water (DCW)
6. Heizungs-Rücklauf (HRL) /
AN33376446555601-000101

DIMENSIONAL SKETCH

3 4 5
3 4 5 6
65 65 65
410
3 4 5
Heating (HE) supply
Domestic hot water (DHW)
District heating (DH) supply
District heating (DH) return
Heating (HE) return
145X2025
EvoFlat Reno
6 7 8
95
204
1. Heizk. vorlauf
2. WW
3. Primär vorlauf
4. Primär rücklauf
5. KW
6. Heizk. rücklauf
6 7 8
© Danfoss | Produced by Danfoss Redan A/S | 2020.02 | 13
9 10 11
General tolerance accuracy, measurements without tolerance: Projection Scale Size Material
ISO 2768 - mK
1:2.5 A2
39.03 kg
Weight
Danfoss Standard
Designation
Replace
Design 11-07-2018 HMS
Approval
Danfoss Redan A/S
No. Evoflat Reno
Confidential: Property of Danfoss Redan A/S, Nordborg, Denmark.
Not to be handed over to, copied or used by third party. Two- or three
Rev.
dimensional reproduction of contents to be authorized by Danfoss Redan A/S.
9 10 11
12
A
B
C
D
E
F
G
H
Sheet 1 / 1
12
