Abb. 1: TH LINK (Vorder- und Seitenansicht)
TH LINK | Trebing & Himstedt Prozeßautomation GmbH & Co. KG
ETH
[8]
RUN
BUS
A B C D
Aufbau des TH LINK
TH LINK
Part No.:
10003006
HW-Release:
2.0
Serial No.:
000000
Temperature:
0 to +50 °C
Current:
190 mA max.
Power Supply: 19.2 to 28.8 V DC
+ –
24 V DC
ETH:
Ethernet (green/red)
RUN:
OK (green) | Error (red)
BUS:
PROFIBUS (green/red)
Trebing & Himstedt Prozeßautomation GmbH & Co. KG
[7]
Made in Germany
www.t-h.de
