Operating instructions
LED Strobe Light
Item no. 1694482 (red)
Item no. 1674345 (orange)
Intended use
When connected to the operating voltage (12 -24 V/DC), the LED strobe light will generate
regular short flashes of light (flash rate of 7.62 Hz and 24.75 Hz depending on the connection).
Due to this feature the LED flash light can be used e.g. for signalling in alarm systems,
generating light effects or the indication of operating conditions.
The product may be installed and used outdoors and indoors (IP65).
For safety and approval purposes, you must not rebuild and/or modify this product. If you use
the product for purposes other than those described above, the product may be damaged.
In addition, improper use can cause hazards such as short circuiting, fire, electric shock etc.
Read the instructions carefully and keep them. Make this product available to third parties only
together with its operating instructions.
This product complies with the statutory national and European requirements. All company
names and product names are trademarks of their respective owners. All rights reserved.
Delivery content
• LED Strobe Light
• 2x stickers "Fire"
• 2x stickers "Alarm"
• Operating instructions
Latest operating instructions
Download the latest operating instructions via the link www.conrad.com/downloads or scan the
QR code shown. Follow the instructions on the website.
Explanation of symbols
An exclamation mark in a triangle indicates important instructions in this operating
manual that absolutely have to be observed.
The arrow symbol indicates specific tips and advice on operation.
Safety instructions
Read the operating instructions carefully and especially observe the safety
information. If you do not follow the safety instructions and information
on proper handling in this manual, we assume no liability for any resulting
personal injury or damage to property. Such cases will invalidate the warranty/
guarantee.
• The device is not a toy. Keep it out of the reach of children and pets.
• Do not leave packaging material lying around carelessly. This may become
dangerous playing material for children.
• Protect the product from extreme temperatures, strong jolts, flammable gases,
vapours and solvents.
• Do not place the product under any mechanical stress.
• If it is no longer possible to operate the product safely, take it out of operation and
protect it from any accidental use. Safe operation can no longer be guaranteed
if the product:
- is visibly damaged,
- is no longer working properly,
- has been stored for extended periods in poor ambient conditions or
- has been subjected to any serious transport-related stresses.
• Please handle the product carefully. Jolts, impacts or a fall even from a low height
can damage the product.
• Also observe the safety and operating instructions of any other devices which are
connected to the product.
• Do not use the product in rooms with adverse environmental conditions, where
combustible gases, vapours or dust are or may be present! There is a risk of
explosion!
• Regular flashing of the light source may trigger epileptic seizures in certain people.
This may also happen to people who have never before experienced an epileptic
seizure.
• In commercial institutions, the accident prevention regulations of the Employer's
Liability Insurance Association for Electrical Systems and Operating Facilities are
to be observed!
• Consult an expert when in doubt about operation, safety or connection of the
device.
• Maintenance, modifications and repairs are to be performed exclusively by an
expert or at a qualified shop.
• If you have questions which remain unanswered by these operating instructions,
contact our technical support service or other technical personnel.
• Attention, LED light:
- Do not look directly into the LED light!
- Do not look into the beam directly or with optical instruments!
Assembly
• The LED strobe light can generate flashes of light at two different flash rates; depending on
the connection, the flash frequency is 7.62 Hz or 24.75 Hz:
Flash frequency 7.62 Hz
Black wire GND/negative terminal (-)
Red wire positive terminal (+): 12 - 24 V/DC
Flash frequency 24.75 Hz
Black wire GND/negative terminal (-)
Yellow wire positive terminal (+): 12 - 24 V/DC
If only need one flash rate is required, insulate the unused wire (e.g. with shrink
tubing).
Depending on the desired function, it is possible to switch between the flash rates
(e.g., using an external switch, etc.).
• Depending on the surface, the LED strobe light must be secured with two suitable screws,
and wall plugs if necessary. However, before this, a large enough opening for the connecting
cable is needed.
Protect the connecting cables from short-circuit. When installing the product outdoors,
make sure that moisture cannot penetrate the cable connections (e.g. screw connections,
terminals).
Take care not to damage any existing electrical wiring, gas or water pipes, when you
are drilling holes or the tightening screws.
• Switch on the mains voltage and check that the LED strobe light is working.
Care and cleaning
• The product does not require maintenance. The LED bulb is permanently installed and
cannot be replaced.
• Only the outer surface of the LED strobe light should be wiped using a clean, soft, dry cloth.
• Do not use any aggressive cleaning agents, rubbing alcohol or other chemical solutions as
they can cause damage to the housing and malfunctioning.
• Do not press too hard on the housing, as scratches might appear.
• Dust can easily be removed using a clean, soft brush and a vacuum cleaner.
• Do not immerse the product in water.
Disposal
Electronic devices are recyclable waste and must not be disposed of in the
household waste. At the end of its service life, dispose of the product according to
the relevant statutory regulations.
You thus fulfil your statutory obligations and contribute to the protection of the
environment.
Technical data
Operating voltage ......................... 12 - 24 V/DC
Power consumption ...................... max. 120 mA
Lamp ............................................. LED, not replaceable
Protection class ............................ IP65
Flash frequency ............................ 7.62 Hz or 24.75 Hz (depending on connection)
Cable length ................................. approx. 160 mm
Dimensions (W x H x D) ............... 110 x 35 x 38 mm
Weight .......................................... 53 g
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in
electronic data processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited.
This publication represent the technical status at the time of printing.
Copyright 2018 by Conrad Electronic SE. *1694482_1674345_V1_0518_02_mxs_m_en
