controller after switching-on of the voltage supply detects at the input of the black JR-
plug a servo pulse, it automatically switches to the telemetric data depicting mode.
Within this mode the controller ignores any commands of the JetiBox keys.
The following data are shown on the JetiBox LCD:
Actual power in percent:
R 80% - the motor is running, the percent value shows the motor voltage
B 100% - the motor is braking, the percent value shows the braking effectivity
B 0% - Motor-Stop, without brake
Actual motor r.p.m.:
this value is shown in the upper right corner of the display. The value is converted
accordingly to the controller set-up (number of motor poles and gear reduction ratio) and
is indicated in r.p.m.
Actual voltage:
in the lower left corner there is shown the actual battery voltage.
Actual temperature:
in the lower right corner the actual controller temperature is shown.
Error status:
in case of an error the error status is shown in the center of the lower line.
U - the controller has detected a supply voltage value which lies below the set switch-
off voltage
C - a commutation error occurred, the controller has detected a reading error while
reading the motor position
T - the controller temperature protection has been activated, the set maximum
temperature has been exceeded

4. Setting with the help of the R/C equipment

In manual setting menu (MAN Setting), the item Setting thru R/C must be ON (factory preset).
Setting process:
1.connect the controller by means of the JR connector to the receiver throttle channel and connect the
motor.
2.shift the throttle stick to position „full throttle", switch on the transmitter and connect the flight
batteries.
3.switch on the switch - receiver power supply (void for SPIN 11), after five seconds four tones sound. If
the throttle stick is immediately shifted back to low throttle position the value of the full throttle
