Device Description - Narex ASV 120-2 BASIC Original Bedienungsanleitung

English
Table of contents
Device Description ............................................................................18
Technical Information ......................................................................18
General Power Tool Safety Warnings .............................................19
Special safety instructions for drills ................................................19
Charger safety warnings ..................................................................20
Information about noise level and vibrations ..............................20
Use .......................................................................................................20
Double insulation ..............................................................................20
Accumulator Battery Charge Instructions .....................................20
Commissioning - ASV 120-2 ...........................................................21
Getting Started - AS 120 ..................................................................21
"TRAFFIC LIGHT" LED indicator (9) .................................................22
Maintenance and service .................................................................22
Accessories..........................................................................................22
Storage ................................................................................................22
Environmental protection ................................................................22
Warranty .............................................................................................22
Certificate of Conformity ..................................................................23
Technical Information
Type
Voltage (V)
Idle speed (rpm)
Max� torque (Nm)
Chuck - scope of clamping (mm)
Wood screws - dia� max� (mm)
Drilling - dia� max� (mm)
Threaded spindle for chuck
Weight w/o accumulators (kg)
Recommended charger
Recommended batteries
Charger
Type
Input voltage (V)
Frequency (Hz)
Power input (W)
Output voltage (V)
Electric charge current (A)
Charge time (min):
Weight (kg)
Protection rating
Battery
Type
Voltage (V)
Cell types
Capacity (Ah)
Battery watt-hour (Wh)
Charge temperature (°C)
Charge time (min)
Charge temperature monitoring
Weight (kg)
18
Cordless drill/driver ASV 120-2 BASIC; ASV 122-2
Cordless LED Flashlight AS 120
Original operating manual (EN)
1st range
2nd range
into metal
into wood
AP 122
AP 123

Device Description

1 �������Accumulator Battery
2 �������Battery clamp
3 �������Switch button with speed regulation
4 �������Rotation direction switch
5 �������Speed switch
6a �����Set collar for torque set-up
6b �����Mode switch: tighten / drill / hammer
7 �������Work space LED lighting
8 �������Chuck
9 �������LED Indicator
10 �����Charger
11 �����Charge LED indicators
12 �����Flashlight push button switch
13 �����Spherical reflector
The accessories displayed or described here may not be in-
cluded in the delivery.
ASV 120-2
12�0
0-350
0-1 350
35
0�8-10
6
10
30
3/8"-24 UNF
0�92
ANU 1220
AP 122, AP 123
ANU 1220
220-240
50-60
80
12�6 / 21�0
3 / 4
about 35
about 45
0�48
II /
ASV 122 ASV 123
12�0
Li-Ion
2�0 3�0
21�6 32�4
0-45
About 25 About 30
With a thermistor
0�18 0�19
