8

Putting out of operation

Lock external compressed air supply
Move valve lever down
Remove the compressed air hose from the device
Any material residues should be removed with a sponge cloth
9

Cleaning

Use a moist cloth to clean the device and make sure that no water penetrates into the device. Do not use aggressive cleaning
GB
agents (scouring powder, solvents).
- 6 -
The device constists of makrolon components which may only be cleaned with mild agents or ethanol (96 %).
10

Maintenance

Attention!
When blowing off the safety valves, please note thas gases can exhaust in high velocity and with high temperature
and excessive noise.
In the event of minor leaks, which may be caused by contamination between the sealing surface, the valve can be made to
blow off through lifting, for cleaning purposes.
In the case of safety valves with a lifting device it is recommended, that the valves from time to time must be made to blow-
off by lifting the seal off the seat, in order to assure the correct functioning of the safety valve.
They can be made to open by hand at the latest when the working pressure is > 85 % of the response pressure.
Lifting is carried out by turning the twist-type lifting mechanism above the bonnet in a counterclockwise direction. Turn the
twist-type lifting mechanism back to the stop again afterwards.
11

Technical data

Pressure connection
Nominal pressure
Max. operating pressure
Dimensions
Height 300 mm
Width 305 mm
Depth 400 mm
Weight
12

Service

We appreciate your comments, feedback, and suggestions.
More information about our product range "metallography" are available by the displayed QR code or at
our website www.kulzer-technik.com
www.kulzer-technik.com/Metallography
Required utility space
approx. 450 mm
approx. 315 mm
approx. 550 mm
3 bis 10 bar
2 bar
2,8 bar
Dimensions pressure pot
Inner diameter
Inner diameter bottom
Height of pressure pot to lid edge
8,6 kg
approx. 210 mm
approx. 225 mm
approx. 190 mm
