VENTILATION AIR INTAKE ASSEMBLY

Remove the elliptical neck that is secured by screws.

Remove the protection plate that covers the external air intake and reattach the elliptical neck.

Double or cut the lid at the bottom of the pressure dampers to allow the air to pass.

Airzone thermostats are mounted on the wall through a support. It is recommended not to locate it more than 40 meters away

from the main control board. To fix it to the wall, follow these steps:

Separate the back part of the thermostat from the wall support.

If your thermostat is wired make all the connections, if your thermostat is

wireless insert the CR2450 button battery.

Fix the back part of the thermostat to the wall.

Place the display on the support once it is fixed.

Place the anti-theft rods for additional support (optional).
