Microphone Stand Mounting Accessory (Sold Separately)

The MixPad MXP124 and MXP124FX can be mounted to a microphone stand
using the optional Mic Stand Mount accessory kit. The following steps describe
how to mount the MixPad mixer to a microphone stand.
1. Turn the mixer upside down.
2. Align the Mic Stand Mount
screws (A) with the MixPad
threaded inserts (B).
3. Screw the Mic Stand
Mount to the MixPad mixer,
ensuring that the two screws
are securely tightened.
4. Turn the mixer over and
affix the mount onto a
microphone stand.
5. To adjust the angle of the
mixer, loosen the wing-nut (C), rotate
the mixer to the desired angle then re-
tighten the wing-nut.
Note: Take care when placing the
mixer on a stand, to ensure that it is
on a level, steady surface and will not
tip over. Arrange the cables parallel
to the microphone stand with enough
slack so the cables are not pulling the
mixer.
22
A
A
B
B
C
