Color LaserJet Pro
MFP M477
Getting Started Guide
IMPORTANT:
Follow Steps 1 - 3 on the
printer hardware setup
poster, and then continue
with Step 4.
1
5. Select a connection method and prepare for software installation
USB connection directly between the
printer and the computer
Use an A-to-B type USB cable (not included with all models).
Windows
1. Do not connect the USB cable before installing the software. If the cable
is already connected, disconnect it before continuing. The installation
process prompts to connect the cable at the appropriate time.
2. Continue with "6. Locate or download the software installation files."
NOTE: During software installation, select the option to Directly connect
this computer using a USB cable. (Windows only)
Mac
1. For Mac, connect the USB cable between the computer and the printer
before installing the software.
2. Continue with "6. Locate or download the software installation files."
Wired (Ethernet) network connection
Use a standard network cable. (Cable not included.)
1. Connect the network cable to the printer and to the network. Wait a few
minutes for the printer to acquire a network address.
2. On the control panel, touch the Connection Information
If an IP address is listed, the network connection has been established.
If not, wait a few more minutes and try again. Note the IP address for use
during software installation. Example IP address: 192.168.0.1
To manually configure the IP address, see
IP address."
3. Continue with "6. Locate or download the software installation files."
NOTE: During software installation, select the option to Connect through
a network. (Windows only)
www.hp.com/support/colorljM477MFP
4. Initial setup on the control panel
After turning on the printer, wait for it to initialize. To navigate the control panel, use touch, swipe, and
scroll gestures. Follow the prompts on the control panel to configure these settings:
• Language
• Location
• Default Settings
Under Default Settings select one of these options:
• Self-managed: Optimized default settings for most users that include guided setup and
configuration steps and automatic updates.
• IT-managed: Optimized default settings for fleet manageability.
Settings are fully customizable after initial setup.
NOTE: Select Print Information Page to print a page that instructs how to change the default
settings.
NOTE: Touch the Help button on the printer control panel to access help topics.
button.
"Manually configure the
www.register.hp.com
Built-in wireless network connection
1. Touch the Connection Information
2. Touch the Network Wi-Fi OFF button.
3. Touch the Settings button.
4. Touch the Wireless Setup Wizard item.
5. Select the correct network SSID from the list. If you do not see the SSID,
touch Enter SSID and provide the network SSID manually.
6. Use the keyboard to enter the passphrase, and then touch the OK button.
7. Wait while the printer establishes a network connection.
8. Touch the Connection Information
listed, the network connection has been established. If not, wait a few
more minutes and try again. Note the IP address for use during software
installation. Example IP address: 192.168.0.1
9. To print from a computer, continue with
software installation files."
with "8. Mobile and wireless printing."
NOTE: During software installation, select the option to Connect through
a network. (Windows only)
Manually configure the IP address
See the printer user guide for information on how to manually configure the
IP address. See the "Troubleshooting"
1
2
English .............. 1
Français ............ 4
Deutsch ............. 7
Italiano ........... 10
Español ........... 13
Català ............. 16
Dansk ............. 19
Nederlands ...... 22
Suomi ............. 25
Norsk .............. 28
Português ....... 31
Svenska .......... 35
button.
button. If an IP address is
"6. Locate or download the
To print from a phone or tablet only, continue
section of this guide.
