1 • UNDERSTANDING YOUR STEAM GENERATOR
1 2 3 4
5
1. "Precision Steam Jet" nozzle
(depending on the model)
2. "Precision Steam Jet" button
(depending on the model)
3. Humid steam button
(depending on the model)
4. Steam control button
5. Temperature control dial for iron soleplate
6. Iron temperature control light
7. Steam generator boiler (in the base unit)
8. Cord fastener

Control panel

Green "steam
ready" light
6
18 17
8
Steam output control dial
14
16 15
9. Handles for removing and replacing
the water tank
10. Removable water tank
11. Removable water tank filler cover
12. Iron rest
13. Boiler rinse plug
14. Control panel
15. Power cord storage space
16. Power cord reel button
17. Illuminated on / off switch
18. Iron-base steam cord
"Restart" button
11 10
12
9 7
13
Orange "boiler rinse" light
Red "removable water tank
empty" light
