MDT-tex ZB10111 Bedienungsanleitung Seite 5

01
01
safety instruction:
The MDT-umbrella Type T is good for windy conditions up to 60 km/h (7
Beaufort), but it may only be set up with bases which are recommended by
MDT. in case of upcoming wind, the umbrella must be closed and fixed with
the ribbon immediately. MDT does not assume liability for any damages
causes by the use of the umbrella contrary the instruction manual.
installation instruction:
The distance between each umbrella should be at least 20 cm. The corresponding
distance between the ground ankers, please find in the chart.
in case, after mounting the safety pin does not fit in the whole, which was
designed for it in the mast, anymore, it can be drilled again by hand.
please never use the umbrellas without the safety pin!
#1 square umbrella
#1 Quadratischer Schirm:
l2
Distance groundtube (middle)
Abstand der Bodenhülsen (mittig):
size
3x3
4x4
5x5
6x6
ø 4 (8-eck)
ø 5 (8-eck)
ø 6 (8-eck)
#1 round umbrella (octagonal)
l 1 Distance groundtube
300 cm 320 cm
400 cm 420 cm
500 cm 520 cm
600 cm 620 cm
400 cm 420 cm
500 cm 520 cm
600 cm 620 cm
l1
l 2
424 cm
565 cm
707 cm
848 cm
370 cm
462 cm
554 cm
5
Typ T / Type T
wall
:
45°
l2
Distance groundtube
444 cm
585 cm
727 cm
868 cm
390 cm
482 cm
574 cm
all data are approximate data without guarantee
90°
ground tube
. .
