Connection to the ports
RGB
1
D-sub 15pin mini shrink jack
11 12
12 13
13 14
14 15
15
6
7
8
9
10
10
1
2
3
4
5
At RGB signal
• Video signal: RGB separate, Analog, 0.7Vp-p, 75Ω terminated (positive)
• H/V. sync. Signal: TTL level (positive/negative)
• Composite sync. Signal: TTL level
At component video signal
• System: 525i (480i), 525p (480p), 625i (576i), 750p (720p), 1125i (1080i)
At RGB signal
Pin
1
Video Red
2
Video Green
3
Video Blue
4
(No connection)
5
Ground
6
Ground Red
7
Ground Green
8
Ground Blue
9
(No connection)
10 Ground
11 (No connection)
12 SDA (DDC data)
13 H. sync / Composite sync.
14 V. sync.
15 SCL (DDC clock)
CONTROL
RGB
K K
Signal
Signal
S-VIDEO
VIDEO
1
At component video signal
Pin
1
C
R
Y
2
C
3
B
(No connection)
(No connection)
4
Ground
5
C
6
R
Y Ground
7
C
8
B
(No connection)
(No connection)
9
Ground
10
11
15
* except for RGB OUT.
Technical (continued)
AUDIO
Signal
Signal
/P
R
/P
B
/P
Ground
R
/P
Ground
B
(No connection)
3
