2
BALANCED INPUT LEFT/RIGHT
Left and right-hand balanced inputs (XLR / 6.3 mm jack combo). In the mono mode, only the right input (RIGHT) may be used.
3
PAD
Switchable level attenuation for high input level.
Switch in position -12 dB: Attenuation of the input signal by 12 db.
Switch in position 0 dB: No attenuation of the input signal.
4
ANTENNA
BNC antenna connector 50 Ohm.

BELT PACK TRANSMITTER

BELT CLIP
Clip the receiver to your belt or a suitable strap. For optimum fit, the clip should always be pushed all the way over the belt and/or strap
(see illustration).

BATTERY REPLACEMENT

To replace the batteries, press gently on the marked spots on the sides of the battery cover and flip it forward. Remove the batteries,
insert two new AA-batteries (for orientation please see the illustration in the battery compartment) and close the cover. Remove the
batteries when the device is not in use for an extended period.
