1
3
The reverse process should be done. First, the rubber cam is introduce
in the red rubber tap, pins must be put into the slots, as seen in fi gure 4 (step
1). Next, press at point mark in step 2, un l the fl ange and the axis are perfectly
inserted (step 2).
At this moment, red rubber tap is introduced in the body tap (step 3).
Please , be sure that all the fl anges and axis are in correct posi on, as show in
step 4 and 5.
Next, you have to join the puller with the body tap, but fi rstly you must
lubricate the cylindrical part of the puller (fi gure 5, step 1) and introduce it in
the gap of the body tap in a sidewise movement (fi gure 5, step 2), then the
spring must be tauten as is indicated in fi gure 5 (step 4), in order to change its
posi on from the lever fl ange to the body fl ange (rectangle).
1
ANEXO MANUAL SL310008820 Ed.03 12/2013
2
4
FIGURE 4
2
5
4
3
FIGURE 5
P - 7
