INSTALLATION OF DEEP PLANING GUIDE
Place the deep planing guide (12) in the guide (on the right side) in the planer body and secure with the
locking knob for deep planing guide (13) (included) (fig. E).
Use the scale on the deep planing guide (12) to set planing depth.
PLANING DEPTH ADJUSTMENT
Planer front footplate (6) is movable and it allows for planing depth adjustment.
Planing depth can be adjusted with the knob for planing depth adjustment (1) and the range is 0 – 3.5 mm,
shown on the planing depth scale (7) located on its circumference (fig. F).
SWITCHING ON / SWITCHING OFF
The mains voltage must match the voltage on the rating plate of the planer. Hold the planer with
both hands when starting up and during operation.
The planer features switch that protects against unintentional starting up.
Switching on:
Press the switch lock button (3) (fig. G).
Press the switch button (2).
Switching off:
Release pressure on the switch button (2).
Hold the planer firmly with both hands before switching it on. Switch on the planer only when the
front footplate rests on the material that you plan to process and the planer blades do not touch
material. This position prevents too early contact of blades with material. Start the work only after
the planer reaches its top rotational speed.
When using the planer, try to position planer footplate and surface of processed material in parallel. Guide the
planer with both hands, move it smoothly and continuously on the material surface. Effects of work depend
on speed of planer movement and depth of planing. Coarse processing uses bigger planing depth. During
fine processing it is recommended to set small planing depth and to proceed with work in few runs.
Do not press the planer too hard. Pressure should be moderate and uniform on the whole surface
of contact of foot and processed material. Applying too big pressure causes undesirable drop of
rotational speed, motor overheating, damage of processed material and parts of the planer. Make
periodic breaks in operation.
DEEP PLANING
You can use the deep planing guide and the parallel guide to make hollows in material.
Attach the parallel guide (9) and the deep planing guide (12).
Set planing width and depth.
Process the material (fig. H).
PROCESSING CORNERS (CHAMFERING)
V-grooves (18) located on the front footplate (6) (fig. I) allow for quick processing (chamfering) of edges
of processed material. Place one of the V-grooves on the edge of processed material and move the planer
forward, make sure to keep the 45
PARK REST
Park rest (22) allows to put away the planer safely during operation without the risk of damaging processed
surface or the planer blades. The park rest (22) lifts up when processing and releases the back footplate of
the planer (fig. L).

OPERATION / SETTINGS

0 angle (fig. J).
