Controls the boost and cut of the low-frequency response of the pre-amplifier.
4
Para-Mid Frequency control selects the mid-frequencies (200Hz to 2KHz) to be cut or boosted with the Par-Mid
5
Level control (6).
6
Para-Mid Level control cuts (anti-clockwise) or boosts (control clockwise) the frequency selected with the Para-
Mid frequency control (5).
Controls the boost and cut of the high-frequency response of the pre-amplifier.
7
8 Sets the overall output level of the amplifier.
9 AUX IN provided for connecting an external sound source such as; CD players, MP3 players etc.
Socket for connecting headphones. With headphones connected, the internal loudspeaker is automatically
10
switched off.
Send and return sockets are provided for connecting external effects-units. You can also use the Send socket as a
11 12
line out if you wish. RB3 ONLY.
13 This socket provides a balanced low-impedance output-signal (Pre EQ) for connection to a mixing desk. Check
out the block diagram on page 9.
Indicates power is connected and the amplifier is switched on.
14
Always switch off and disconnect power cord when not in use.
