133mm
5" 15/64
13mm
33/64"
MAX. 18mm
MAX. 45/64"
3/8" GAS
Ø 35mm
Ø 1" 3/8
100mm
3" 15/16
Dimensioni d'ingombro e quote di fissaggio
Overall dimensions and fixing points
Dimensions d'encombrement et fixations
Maßen und Befestigungshöhe
118mm
4" 41/64
Ø 21mm
Ø 53"64"
Ø 60mm
65mm
Ø 2" 23/64
2" 9/16
Ø 20mm
Ø 25/32"
Schema di foratura - Drilling's diagram
Schème de percement - Lochenschablone
Ø 35mm
Ø 1" 3/8
100mm
3" 15/16
Ø 45mm
Ø 1" 49/64
50°
5mm
13/64"
MAX. 50mm
MAX. 1" 31/32
Ø 20mm
Ø 25/32"
100mm
3" 15/16
-3-
Ø 24mm
Ø 15/16"
190mm
7" 31/64
Ø 35mm
Ø 1" 3/8
130mm
5" 1/8
Ø 40mm
Ø 1" 37/64
100mm
3" 15/16
Ø 35mm
Ø 1" 3/8
